ER40 collet, Hole Size 7/16 inch Tool holding range 0.438" to 0.398" Made of high alloy spring steel Hardened surface…
ER40 COLLET 7/16 inch hole size
- ER40 collet, Hole Size 7/16 inch
- Tool holding range 0.438″ to 0.398″
- Made of high alloy spring steel
- Hardened surface to 44-48 HRc
- Maximum gripping force with 16 jaws
- Runout precision of 0.0006″ (Concentricity of .0003″)
$18.00
7 in stock
Can be mounted on Milling Machine Table Fit on Lathe using a Back Plate Diameter of base plate : 3.94"(100mm)…
ER40 Collet Chuck 100mm Base-plate
- Can be mounted on Milling Machine Table
- Fit on Lathe using a Back Plate
- Diameter of base plate : 3.94″(100mm)
- ER40 holding capacity range : 1/8-1″( 3-26mm)
$149.20
Out of stock
Diameter: 63mm (2.5") Length: 25.5mm (1") Thread: M50x1.5mm Order related Spanner : 3006-0110
ER40 COLLET NUT
- Diameter: 63mm (2.5″)
- Length: 25.5mm (1″)
- Thread: M50x1.5mm
- Order related Spanner : 3006-0110
$20.00
15 in stock
9 pieces of ER11 with hole Sizes : 1, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5mm Made of high…
ER8 Collet SET METRIC, 9 Pieces
- 9 pieces of ER11 with hole Sizes : 1, 1.5, 2, 2.5, 3, 3.5, 4, 4.5, 5mm
- Made of high alloy spring steel.
- Hardened surface to 44-48 HRc
- Maximum gripping force with 16 jaws
- Runout precision of 10µm (Concentricity of 5µm)
- Available both in imperial and metric sizes
$239.00
1 in stock
Diameter : 12mm Thread : M10x0.75mm Length : 10.8mm Order related Spanner : 3006-0010
ER8 MINI COLLET NUT
- Diameter : 12mm
- Thread : M10x0.75mm
- Length : 10.8mm
- Order related Spanner : 3006-0010
$26.00
41 in stock
Made of Special Steel 58-62 HRC Balanced G2.5 at 20,000RPM Gauge length : 4"
HSK 100 A ER16 COLLET HOLDER 4″
- Made of Special Steel 58-62 HRC
- Balanced G2.5 at 20,000RPM
- Gauge length : 4″
$290.00
2 in stock
Made of Special Steel 58-62 HRC Balanced G2.5 at 20,000RPM Gauge length : 4"
HSK 100A ER32 COLLET HOLDER 4″
- Made of Special Steel 58-62 HRC
- Balanced G2.5 at 20,000RPM
- Gauge length : 4″
$290.00
2 in stock
Taper : HSK63A Type : Shell Mill Holder / Face Mill Arbor Arbor Size : 1" Gage Lengths : 2.76"…
HSK63A 1″ 2.76″ Shell Mill Holder
- Taper : HSK63A
- Type : Shell Mill Holder / Face Mill Arbor
- Arbor Size : 1″
- Gage Lengths : 2.76″
- Clamping System: Drive keys and cap screw for secure cutter mounting
- Material: High-grade alloy steel, hardened & precision ground
- Runout Accuracy : les than 0.0001″
- Balance Grade: G2.5 @ 25,000 RPM (suitable for high-speed cutting)
- Coolant Capability: Through-spindle coolant compatible
- Finish : Precision ground with anti-corrosion treatment
- Brand : NOBL Tooling
$148.50
10 in stock
Taper : HSK63A Type : Shell Mill Holder / Face Mill Arbor Arbor Size : 1" Gage Lengths : 4"…
HSK63A 1″ 4″ Shell Mill Holder
- Taper : HSK63A
- Type : Shell Mill Holder / Face Mill Arbor
- Arbor Size : 1″
- Gage Lengths : 4″
- Clamping System: Drive keys and cap screw for secure cutter mounting
- Material: High-grade alloy steel, hardened & precision ground
- Runout Accuracy : les than 0.0001″
- Balance Grade: G2.5 @ 25,000 RPM (suitable for high-speed cutting)
- Coolant Capability: Through-spindle coolant compatible
- Finish : Precision ground with anti-corrosion treatment
- Brand : NOBL Tooling
$161.80
9 in stock
Hardened to 62HRC Maximum 360º gripping along the bore High Precision Grinding Slim Body Design Coolant Through Spindle Rigid Construction…
HSK63A 1/2 x 4.3″ Shrink Fit Holder Coolant Thru
- Hardened to 62HRC
- Maximum 360º gripping along the bore
- High Precision Grinding
- Slim Body Design
- Coolant Through Spindle
- Rigid Construction Provides stability during heavy cutting
- Extended Tool Life Reduces vibration and heat buildup
- Wide Tool Compatibility Works with carbide and HSS tools
- For Demanding Applications Suitable for aerospace and automotive machining
- Concentricity : 0.0001″/0.003mm
- Dynamically balanced to G2.5 @ 25,000RPM
- Bore Diameter D1 : 1/2
- Nose Diameter D : 0.8150″
- Largest Diameter D2 : 1.1339″
- Projection Gauge Length L : 4.3″
- Brand : NOBL Tooling
$247.75
8 in stock
Hardened to 62HRC Maximum 360º gripping along the bore High Precision Grinding Slim Body Design Coolant Through Spindle Rigid Construction…
HSK63A 1/4 x 4.3″ Shrink Fit Holder Coolant Thru
- Hardened to 62HRC
- Maximum 360º gripping along the bore
- High Precision Grinding
- Slim Body Design
- Coolant Through Spindle
- Rigid Construction Provides stability during heavy cutting
- Extended Tool Life Reduces vibration and heat buildup
- Wide Tool Compatibility Works with carbide and HSS tools
- For Demanding Applications Suitable for aerospace and automotive machining
- Concentricity : 0.0001″/0.003mm
- Dynamically balanced to G2.5 @ 25,000RPM
- Bore Diameter D1 : 1/4
- Nose Diameter D : 0.5512″
- Largest Diameter D2 : 0.9055″
- Projection Gauge Length L : 4.3″
- Brand : NOBL Tooling
$247.75
8 in stock
Hardened to 62HRC Maximum 360º gripping along the bore High Precision Grinding Slim Body Design Coolant Through Spindle Rigid Construction…
HSK63A 1/8 x 4.3″ Shrink Fit Holder Coolant Thru
- Hardened to 62HRC
- Maximum 360º gripping along the bore
- High Precision Grinding
- Slim Body Design
- Coolant Through Spindle
- Rigid Construction Provides stability during heavy cutting
- Extended Tool Life Reduces vibration and heat buildup
- Wide Tool Compatibility Works with carbide and HSS tools
- For Demanding Applications Suitable for aerospace and automotive machining
- Concentricity : 0.0001″/0.003mm
- Dynamically balanced to G2.5 @ 25,000RPM
- Bore Diameter D1 : 1/8
- Nose Diameter D : 0.4331″
- Largest Diameter D2 : 0.7874″
- Projection Gauge Length L : 4.3″
- Brand : NOBL Tooling
$247.75
8 in stock
Hardened to 62HRC Maximum 360º gripping along the bore High Precision Grinding Slim Body Design Coolant Through Spindle Rigid Construction…
HSK63A 10mm x 4.3″ Shrink Fit Holder Coolant Thru
- Hardened to 62HRC
- Maximum 360º gripping along the bore
- High Precision Grinding
- Slim Body Design
- Coolant Through Spindle
- Rigid Construction Provides stability during heavy cutting
- Extended Tool Life Reduces vibration and heat buildup
- Wide Tool Compatibility Works with carbide and HSS tools
- For Demanding Applications Suitable for aerospace and automotive machining
- Concentricity : 0.0001″/0.003mm
- Dynamically balanced to G2.5 @ 25,000RPM
- Bore Diameter D1 : 6mm
- Nose Diameter D : 0.6629″
- Largest Diameter D2 : 1.008″
- Projection Gauge Length L : 4.3″
- Brand : NOBL Tooling
$247.75
3 in stock
Hardened to 62HRC Maximum 360º gripping along the bore High Precision Grinding Slim Body Design Coolant Through Spindle Rigid Construction…
HSK63A 3/16 x 4.3″ Shrink Fit Holder Coolant Thru
- Hardened to 62HRC
- Maximum 360º gripping along the bore
- High Precision Grinding
- Slim Body Design
- Coolant Through Spindle
- Rigid Construction Provides stability during heavy cutting
- Extended Tool Life Reduces vibration and heat buildup
- Wide Tool Compatibility Works with carbide and HSS tools
- For Demanding Applications Suitable for aerospace and automotive machining
- Concentricity : 0.0001″/0.003mm
- Dynamically balanced to G2.5 @ 25,000RPM
- Bore Diameter D1 : 3/16
- Nose Diameter D : 0.500″
- Largest Diameter D2 : 0.8268″
- Projection Gauge Length L : 4.3″
- Brand : NOBL Tooling
$247.75
8 in stock
Taper : HSK63A Type : Shell Mill Holder / Face Mill Arbor Arbor Size : Ø3/4 Gage Lengths : 2.76"…
HSK63A 3/4 2.76″ Shell Mill Holder
- Taper : HSK63A
- Type : Shell Mill Holder / Face Mill Arbor
- Arbor Size : Ø3/4
- Gage Lengths : 2.76″
- Clamping System: Drive keys and cap screw for secure cutter mounting
- Material: High-grade alloy steel, hardened & precision ground
- Runout Accuracy : les than 0.0001″
- Balance Grade: G2.5 @ 25,000 RPM (suitable for high-speed cutting)
- Coolant Capability: Through-spindle coolant compatible
- Finish : Precision ground with anti-corrosion treatment
- Brand : NOBL Tooling
$124.00
10 in stock
Taper : HSK63A Type : Shell Mill Holder / Face Mill Arbor Arbor Size : Ø3/4 Gage Lengths : 4"…
HSK63A 3/4 4″ Shell Mill Holder
- Taper : HSK63A
- Type : Shell Mill Holder / Face Mill Arbor
- Arbor Size : Ø3/4
- Gage Lengths : 4″
- Clamping System: Drive keys and cap screw for secure cutter mounting
- Material: High-grade alloy steel, hardened & precision ground
- Runout Accuracy : les than 0.0001″
- Balance Grade: G2.5 @ 25,000 RPM (suitable for high-speed cutting)
- Coolant Capability: Through-spindle coolant compatible
- Finish : Precision ground with anti-corrosion treatment
- Brand : NOBL Tooling
$159.00
9 in stock
